Video |
Imaging Device |
1/2.8″ 2MP CMOS |
Resolution |
1920×1080, 1280×960, 1280×720, 800×600, 800×448, 720×576, 720×480, 640×480, 640×360 |
Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 15fps/12fps(60Hz/50Hz) |
Min. Illumination |
Color: 0.03Lux(F2.0, 1/30sec)
BW: 0Lux(IR LED on) |
Video Out |
CVBS: 1.0 Vp-p / 75Ω composite, 720×480(N), 720×576(P) for installation |
Lens |
Focal Length (Zoom Ratio) |
6.0mm fixed focal |
Max. Aperture Ratio |
F2.0 |
Angular Field of View |
H: 52.8 / V: 30.3° / D: 60.4° |
Focus Control |
Fixed |
Pan / Tilt / Rotate |
Pan / Tilt / Rotate Range |
0˚~350˚ / 0˚~67˚ / 0˚~355˚ |
Operational |
Camera Title |
Displayed up to 85 characters |
Day & Night |
Auto(ICR) |
Backlight Compensation |
BLC, WDR, SSDR |
Wide Dynamic Range |
120dB |
Digital Noise Reduction |
SSNR |
Motion Detection |
4ea, polygonal zones |
Privacy Masking |
6ea, rectangular zones |
Gain Control |
Low / Middle / High |
White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
LDC |
Support |
Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (1/5~1/12,000sec) |
Video Rotation |
Flip, Mirror, Hallway view(90˚/270˚) |
Analytics |
Defocus detection, Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line |
Alarm I/O |
Input 1ea / Output 1ea |
Alarm Triggers |
Analytics, Network disconnect, Alarm input |
Alarm Events |
File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC or NAS recording at event triggers
Alarm output |
Audio In |
Selectable(mic in/line in)
Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
IR Viewable Length |
30m(98.42ft) |
Network |
Ethernet |
RJ-45(10/100BASE-T) |
Video Compression |
H.265/H.264: Main/High, MJPEG |
Audio Compression |
G.711 u-law /G.726 Selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps |
Smart Codec |
WiseStreamⅡ |
Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
Streaming |
Unicast(6 users) / Multicast
Multiple streaming(Up to 3 profiles) |
Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP |
Security |
HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access log
802.1X Authentication(EAP-TLS, EAP-LEAP) |
Application Programming Interface |
ONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platform |
General |
Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch |
Web Viewer |
Supported OS: Windows 7, 8.1, 10, Mac OS X 10.12, 10.13, 10.14
Recommended Browser: Google Chrome
Supported Browser: MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OS X only) |
Edge Storage |
Micro SD/SDHC/SDXC 1slot 128GB |
Memory |
512MB RAM, 256MB Flash |
Environmental & Electrical |
Operating Temperature / Humidity |
-30°C ~ +55°C(-22°F ~ +131°F) / Less than 90% RH
* Start up should be done at above -20°C |
Storage Temperature / Humidity |
-30°C ~ +60°C(-22°F ~ +140°F) / Less than 90% RH |
Certification |
IP66, IK10 |
Input Voltage |
PoE(IEEE802.3af, Class3), 12VDC |
Power Consumption |
PoE: Max 7.40W, typical 6.00W
12VDC: Max 6.40W, typical 5.10W |
Mechanical |
Color / Material |
White / Aluminum |
RAL Code |
RAL9003 |
Product dimensions / weight |
Ø120.3×91.7mm(Ø4.74×3.61″), 510g(1.12 lb) |
DORI |
Detect (25PPM/ 8PPF) |
77.4m(253.77ft) |
Observe (63PPM/ 19PPF) |
30.9m(101.51ft) |
Recognize (125PPM/ 38PPF) |
15.5m(50.75ft) |
Identify (250PPM/ 76PPF) |
7.7m(25.38ft) |
